Installing polycarbonate hurricane panels on aluminum framed windows is an effective way to protect your home from severe weather while allowing natural light to enter. These panels are durable, lightweight, and provide excellent impact resistance compared to traditional plywood. This comprehensive guide will walk you through the entire installation process, including preparation, cutting, drilling, mounting, and finishing touches. We will also include helpful images and videos to assist you visually.
- High Impact Resistance: Polycarbonate panels can withstand impacts from flying debris during hurricanes.
- Light Transmission: Unlike plywood, these panels allow natural light to pass through, keeping interiors bright.
- Durability: They resist cracking, yellowing, and UV damage.
- Ease of Installation: Lightweight and easy to handle with basic tools.
- Reusability: Panels can be removed after storms and stored for future use.
- Polycarbonate hurricane panels (sized for your windows)
- Measuring tape
- Circular saw with fine-tooth blade (for cutting panels)
- Drill with masonry and standard bits
- Stud finder (for locating framing studs)
- Anchors and screws or mounting brackets (appropriate for your wall type)
- Washers and wing nuts
- Level
- Marker or pencil
- Safety goggles and gloves
- Ladder (if windows are high)
- Caulk or sealant (optional, for sealing gaps)
Measure the height and width of each aluminum framed window. Add 8 inches to both height and width to allow for a 4-inch overhang on all sides. If your window has a sill, add only 4 inches to the height because the panel will attach flush with the sill using a bracket.
Use a stud finder to locate studs or solid framing behind the aluminum siding or wall surface. Mark these locations carefully, as your panel mounting holes must align with these solid points for secure installation.
Remove any objects near the windows and clean the exterior surface with a mild soap and water solution to ensure proper adhesion if using sealants.
- Use a circular saw with a fine-tooth blade to cut the panels according to your measurements.
- Mark the UV-protected side (usually labeled) to ensure it faces outward during installation.
- Cut carefully to maintain straight edges.
- Mark holes 6 inches from each corner and at least 1 inch from the edges.
- Space additional holes no more than 12 inches apart along the edges.
- Use a step drill bit to drill holes at the marked points.
- Keep the protective film on the panels during drilling to prevent scratching.
- Ensure the UV-protected side faces outward.
- Center the panel over the window opening.
- Use the panel as a template to mark hole positions on the wall, aligning with studs or solid surfaces.
- Drill holes in the wall using a masonry bit for brick or stucco, or a standard bit for wood or aluminum framing.
- Insert appropriate anchors for your wall type.
- If your window has a sill, install mounting brackets on the sill to support the panel's bottom edge.
- Follow the manufacturer's instructions for bracket installation.
- Remove the protective film from the inside of the panel.
- Place the panel over the mounting anchors.
- Place neoprene-bonded washers over each anchor to cushion the panel.
- Secure with flat washers and wing nuts, tightening carefully to avoid over-tightening which could crack the panel.
- Remove the protective film from the outside of the panel after installation.
- Mark the panel's location on the wall for easier reinstallation in the future.
- Optionally, apply caulk or sealant around the edges of the panel to prevent water infiltration.
- After the storm, remove the panels by loosening the wing nuts and washers.
- Cover anchor holes with paintable caps for aesthetics and protection.
- Step-by-step Installation by Lowe's
- Detailed Installation Guide
- Interior Hurricane Panels Installation
Installing polycarbonate hurricane panels on aluminum framed windows is a practical and efficient way to safeguard your home against hurricane damage. These panels offer superior impact resistance, allow natural light, and are reusable season after season. By carefully measuring, cutting, drilling, and mounting the panels with the appropriate hardware, you can ensure a secure fit that meets local building codes and provides peace of mind during storm season. Always follow safety precautions and manufacturer instructions for the best results.
The UV-protected side of the panel is usually labeled or has a printed masking. This side must face outward to protect the panel from sun damage.
Yes, tension clips are an alternative mounting option that does not require drilling, but they are not suitable for all siding types, such as vinyl siding.
Panels should overlap the window opening by at least 4 inches on all sides if there is no sill, or 4 inches on the sides and top and only 4 inches on the height if there is a sill.
Use anchors and screws compatible with aluminum or the wall material, along with neoprene washers and wing nuts for securing the panels without damaging them.
Store panels flat on a raised surface in a cool, dry place away from direct sunlight. Cover them with an opaque material to prevent heat buildup and damage.
